COUGAR ® FUENTE DE PODER XTC 500 WATTS 80+ PFC
Power Conversion Efficiency
Up to 86% efficiency under 230V. A guaranteed highly reliable power supply.
Active Power Factor Correction
High power conversion efficiency. PF value up to 99%, provides clean and reliable power
120mm Extreme Temperature Control
Using COUGAR’s exclusive 120mm silent fan, the advanced frame increase the concentration of air-flow and its fan curvature has been fine-tuned to reduce vibration at any loads, helping you enjoy a quieter gaming experience.
Assigned Japanese Components
XTC includes 105ºC Japanese standby capacitor will keep providing the stable PSU for a long time.
The Japanese polypropylene capacitor minimize the noise during the voltage transition.
Massive Single +12V DC Output
Tight voltage regulation and extreme stability for powerful graphic systems.
*Comparison based on XTC600’s performance data.
Features
Active Power Factor Correction (Active PFC)
PFC value up to 99%, provides clean and reliable p
Compatible with the Newest Components
Created for use with multi-core CPU and PCI express 3.0 graphics cards with 8(6+2) pin PCI-e connector.
Superior Fan Curve Tuning
Advanced technology for noise minimization
105°C Japanese Standby Capacitors
Reliable and durable components that extend the PSU’s useful life.
Strong Safeguards : OCP, OPP, OVP, UVP & SCP
Maximum safety for your key system components
Specifications
| Model Name | AC Input | DC Output | |||||
| +3.3V | +5V | +12V | -12V | +5Vsb | Total | ||
| XTC400 CGR ST-400 | 200-240V~ 50Hz / 5A | 15A | 15A | 30A | 0.3A | 2A | 400W |
| 105W | 360W | ||||||
| XTC500 CGR ST-500 | 16A | 18A | 38A | 0.3A | 2.5A | 500W | |
| 110W | 456W | ||||||
| XTC600 CGR ST-600 | 18A | 20A | 49A | 0.3A | 3A | 600W | |
| 130W | 588W | ||||||
| Model Name | AC Input | DC Output | |||||
| +3.3V | +5V | +12V | -12V | +5Vsb | Total | ||
| XTC450 CGR ST-450 | 200-240V~ 50Hz / 6.3A | 15A | 15A | 34A | 0.3A | 2A | 450W |
| 105W | 408W | 3.6W | 10W | ||||
| XTC550 CGR ST-550 | 16A | 18A | 42A | 0.3A | 2.5A | 550W | |
| 110W | 504W | 3.6W | 12.5W | ||||
| XTC650 CGR ST-650 | 18A | 20A | 52A | 0.3A | 3A | 650W | |
| 130W | 624W | 3.6W | 15W | ||||
| XTC750 CGR ST-750 | 200-240V~ 50-60Hz / 6A | 20A | 20A | 60A | 0.3A | 3A | 750W |
| 120W | 720W | 3.6W | 15W | ||||
| Connector Color Cables |  MB |  CPU |  P-ATA |  S-ATA |  PCI-E |
| Pin | 24(20+4) | 8(4+4) | 4 | 5 | 8(6+2) |
| Length (mm) | 450 | 550 (XTC400) 600 (XTC500) 650 (XTC600) | 450 | 450 | 450 |
| XTC400 | 1 | 1 | 2 | 4 | 1 |
| XTC500 | 1 | 1 | 2 | 5 | 2 |
| XTC600 | 1 | 1 | 2 | 6 | 2 |
| Connector Black Flat Cables |  MB |  CPU |  P-ATA |  S-ATA |  PCI-E |
| Pin | 24(20+4) | 8(4+4) | 4 | 5 | 8(6+2) |
| Length (mm) | 550 (XTC450 / XTC550 / XTC650) 450 (XTC750) | 650 (XTC450 / XTC550 / XTC650) 600 (XTC750) | 450 | 450 | 450 |
| XTC450 | 1 | 1 | 2 | 4 | 2 |
| XTC550 | 1 | 1 | 2 | 5 | 2 |
| XTC650 | 1 | 1 | 2 | 6 | 2 |
| XTC750 | 1 | 1 | 2 | 6 | 2 |
Packing Data
Product Number (P/N)EAN CODEUPC CODEIndividual W/O Packaging
Weight (N.Weight)Individual Packaging
Weight (G.Weight)Individual Size W/O
Packaging (LxWxH)Individual Packaging
Size (LxWxH)
| XTC400 | XTC450 | XTC500 | XTC550 | XTC600 | XTC650 | XTC750 |
| 31XC040.0001P | 31XC450.0001P | 31XC050.0001P | 31XC550.0001P | 31XC060.0001P | 31XC650.0001P | 31TC075032H-01 |
| 4715302442859 4710483770340(UK) | 4710483770692 4710483770722(UK) | 4715302442866 4710483770357(UK) | 4710483770708 4710483770739(UK) | 4715302442873 4710483770364(UK) | 4710483770715 4710483770746(UK) | 4710483770869 4710483770890(UK) |
| 192554001296 | 192554002057 | 192554001302 | 192554002064 | 192554001319 | 192554002071 | 192554002194 |
| 1.2 (Kg) | 1.3 (Kg) | 1.3 (Kg) | 1.35 (Kg) | 1.4 (Kg) | 1.4 (Kg) | 1.4 (Kg) |
| 1.5 (Kg) | 1.6 (Kg) | 1.6 (Kg) | 1.65 (Kg) | 1.7 (Kg) | 1.7 (Kg) | 1.7 (Kg) |
| 140 x 150 x 86 (mm) | ||||||
| 187 X 158 x 165 (mm) | ||||||
Protection
UVP (Under Voltage Protection)
If the voltages fall below a certain tolerance value on the single lines, the PSU automatically switches off.
OVP (Over Voltage Protection)
If the voltages increase above a certain tolerance value on the single lines, the PSU automatically switches off.
SCP (Short-Circuit Protection)
In the case of a short-circuit, this feature prevents damage to the core components of the PSU and its System components.
OPP (Over Power Protection)
If the system is oversized and requires more power from the PSU than it can provide, this protection function is activated.
OCP (Overcurrent Protection)
If the current on a single line is higher than indicated, the PSU automatically switches off.
Safety Standards
